Grade 2 Commercial Exit Lever Lock Hardware Set
Grade 2 Commercial Exit Lever Lock Hardware Set
Grade 2 Commercial Exit Lever Lock Hardware Set
Grade 2 Commercial Exit Lever Lock Hardware Set

Grade 2 Commercial Exit Lever Lock Hardware Set

This ANSI Grade 2 heavy-duty commercial exit lever lock set comes as a complete hardware kit designed specifically for fire exit doors and single-direction restricted access areas. Engineered with a robust cylindrical chassis and finished in sleek satin stainless steel, it restricts any entry from the outside while guaranteeing immediate, effortless egress from the inside during emergencies. This turnkey security solution complies fully with North American life safety and commercial fire codes.
Contact Now
Previous Next
  • Product Information


  • ANSI Grade 2 Certified: Engineered to meet strict North American standards for commercial life safety and fire code compliance.

  • No MOQ Restrictions: Flexible wholesale purchasing with zero minimum order quantity required for standard items.

  • Custom OEM Packaging: Full support for tailored brand packaging and commercial private labeling solutions.

  • Single-Direction Exit Only: Secure, non-functional exterior prevents unauthorized entry while internal lever ensures immediate egress.

  • Turnkey Installation Kit: Includes the active lever assembly, latch, strike plate, and heavy-duty mounting hardware for quick deployment.

  • Door Prep: Cross bore 2-1/8"(54mm), Edge bore 1"(25mm).

  • Door Thick : 1-3/8"(35mm) to 1-3/4"(50mm) thickness Door.

  • Backset: 2-3/4"(70mm) standard. 2-3/8"(60mm) optional.

  • Latch: 1/2 throw dead latch and spring latch

  • Cylinder:6-pin removable core, Schlage C Keyway ，(Kwikset, or C4 keyway optional).

  • Clutch:Clutch (free wheel) function available for ET (Entry)

  • Faceplate: Square corner 1"x1/8"2-1/4"(25.4x57mm) standard, 1"&2-1/4"(25.4x57mm)optional.

  • Strikes: T-Strike 2-3/4"x2-3/4" (44x70mm) standard, ASA-Strike 4-7/8" x 1-1/4"(123.8x31.7mm) optional.

  • Function: DM(0:Dummy), ET(1:Entrance), BK(2:Privacy), PS(3:Passage), ST(4:Storeroom),CL(5:Classroom) CM(8:Communication).

  •                  Ex(9.Exit).
