This glass door floor hinge is a high-strength, precision-built closing system designed for medium to large frameless glass doors in commercial environments. Featuring a pressed-iron body, a durable sanding finish, and a reinforced internal mechanism, the hinge provides stable operating torque for doors up to 110 kg and widths up to 1000 mm.

Its 290 × 103 mm compact structure allows easy integration into floor recesses while maintaining a clean architectural appearance. The hinge also supports multiple spindle standards—C1 (Dorma), A2 (Crown), and M3 (MAB)—ensuring seamless compatibility with global patch fittings and top pivot systems. With adjustable hydraulic control and a robust mechanical layout, this model delivers smooth closing motion, reliable performance, and long service life even under high-volume usage.

1. Compatible with C1 / A2 / M3 Spindle Standards

The hinge includes interchangeable spindle adapters that match worldwide specifications such as Dorma, Crown, and MAB. This universal compatibility allows flexible installation across different brands of glass fittings without requiring customization.

2. Heavy-Duty Pressed-Iron Construction

The main body is made from pressed iron, delivering superior structural strength and impact resistance. This ensures the hinge can reliably support heavy doors up to 110 kg, maintaining stable closing force and alignment even in high-traffic commercial environments.

3. Smooth Hydraulic Motion with Adjustable Speed

A reinforced hydraulic system provides controlled, smooth closing action. Installers can fine-tune the closing speed and final latching force according to the door weight and project needs, enhancing safety and user comfort.

4. Sanding Surface Finish for Durability

The sanding finish resists rust, staining, and surface wear, keeping the hinge clean and visually professional over long-term use. It is well suited for modern glass entrances requiring both durability and a premium aesthetic.

5. Optimized Dimensions for Glass Door Widths up to 1000 mm

With a maximum door width specification of 1000 mm, the hinge is engineered to deliver balanced torque distribution across wider glass panels. This reduces stress on patch fittings and extends the overall lifespan of the door system.

6. Strong Structural Layout for Easy Installation

Clear dimension indicators—such as 275 mm internal body length, 60 mm height, and a 103–130 mm base width—help installers achieve precise recess preparation. The mechanical layout ensures stable positioning and simplifies the alignment process during installation.

1. Retail Store Entrances

Designed for boutique storefronts, shopping malls, and commercial glass entrances where smooth operation, durability, and stability are essential.

2. Corporate Offices and Modern Business Environments

Ideal for reception entrances, meeting rooms, and internal glass partitions. Its quiet hydraulic motion and clean design enhance the professional environment.

3. Hotels, Restaurants, and Hospitality Venues

Suitable for guest access doors, lobby entrances, and high-end interior partitions where both aesthetics and functional reliability matter.

4. Airports, Hospitals, and Public Facilities

Perfect for high-traffic areas requiring long-lasting performance and consistent closing control to ensure safety and convenience.

5. Residential High-End Glass Doors

Applicable in luxury homes, balcony doors, and interior spaces that feature large or heavy glass panels requiring a compact but powerful closing system.
