Commercial Automatic Door Operator Intelligent Electric Swing Door Opening Closer
- Product Information
Silver
Black Aluminium
White Aluminium
DC‑076 Commercial Automatic Door Operator Intelligent Electric Swing Door Opening Closer
DC‑076 heavy‑duty intelligent electric swing door operator for commercial entrance door assemblies. Equipped with DC24V brushless motor, precision gearbox and integrated electronic controller to deliver smooth automatic opening and controlled closing performance. Unit dimension 500 x 80 x 104 mm, accepts AC100‑260V input, provides DC12V/500mA auxiliary output. Adjustable operating speed range 3.5‑15 seconds, maximum opening angle up to 120‑degree. Rated for one‑million opening‑closing service cycles, supports automatic, hold‑open and release working modes. Suitable for door width 800‑1500 mm and maximum door weight 160 kg. Compatible with wooden, metal and fire‑rated door‑sets, widely deployed for hotel, healthcare facility, office, retail store and public‑building entrances. Complete installation hardware and technical documentation included. Monthly production capacity reaches 200,000 units for B2B wholesale architectural automatic swing door operator hardware tender projects.
| Specification | Parameter |
|---|---|
| Product Type | Heavy‑Duty Intelligent Electric Automatic Swing Door Operator |
| Operation | Automatic / Hold‑Open / Release mode, speed 3.5‑15s, max 120° opening angle |
| Material | Aluminium Alloy Housing + DC24V Brushless Motor & Precision Gearbox Control Components |
| Electrical Spec | AC 100‑260V input, DC 12V/500mA auxiliary output |
| Core Functions | Auto‑open & controlled close, one‑million‑cycle rated, multi‑mode operation for commercial swing doors |
| Suitable Door Spec | Door width 800‑1500 mm, Max door weight 160 kg |
| Application | Wooden / Metal / Fire‑Rated Door Assemblies, Hotel, Healthcare, Office, Retail & Public Building Entrances |
| Production Capacity | 200,000 Units / Month |
Application Scenarios
Hotel & Retail Commercial Entrance Installations
Intelligent electric swing door operator for hotel lobby, shopping retail store entrance door‑sets. Smooth automatic opening‑closing action improves user accessibility experience, stable heavy‑duty performance for high‑traffic commercial public entrances.
Healthcare & Public Institution Door Systems
Heavy‑duty automatic swing door operator for hospital, clinic and public‑building access door assemblies. Multi‑working‑mode support meets healthcare accessibility requirements, compatible with fire‑rated door‑sets for institutional building safety specifications.
New‑Build & Architectural Tender Projects
Full installation accessory kit and technical documents included. Suitable for commercial new‑build, refurbishment and automatic swing‑door operator hardware tender specification packages.
Product Characteristics
Heavy‑duty aluminium alloy housing structure, integrated DC24V brushless motor together with precision gearbox and electronic controller for stable intelligent swing‑door operation
Multiple selectable working modes: automatic, hold‑open and release mode; adjustable operating speed 3.5‑15 seconds, maximum opening angle reach 120‑degree
AC100‑260V wide‑range power input, reserved DC12V/500mA auxiliary output interface; endurance rated up to one‑million opening‑closing service cycles
Optimized for door width 800‑1500 mm and maximum door weight 160 kg; supports wooden, metal and fire‑rated swing door assemblies
Comes with complete mounting hardware and technical documents for on‑site commissioning; multiple standard aluminium finish selections available
Monthly capacity 200 000 units for B2B wholesale architectural automatic swing‑door operator hardware orders
Warranty & Customization
Standard quality warranty against manufacturing defects of aluminium housing, brushless motor, gearbox and electronic control components
Bulk wholesale supply for architectural construction tender projects, MOQ 200pcs for formal order
2D installation drawing, electrical wiring diagram and product performance specification datasheet available for tender submission documentation
Frequently Asked Questions
What is the maximum door weight for DC‑076 automatic swing door operator?
DC‑076 intelligent electric swing door operator supports max door weight 160 kg, fits door width 800‑1500 mm, max opening‑angle 120‑degree with one‑million‑cycle service rating.
What working modes does DC‑076 support?
DC‑076 provides automatic, hold‑open and release working modes; adjustable operating speed ranges 3.5‑15 seconds, AC 100‑260V wide‑range power input with auxiliary DC12V output.
Which door‑sets fit DC‑076 automatic swing door operator?
Suitable for wooden, metal and fire‑rated swing‑door assemblies for hotel, healthcare, office, retail and public‑building entrance projects for bulk wholesale orders.
