- Product Information
DB012 Zinc Alloy Interlock Flush Bolt for Aluminium Doors & Windows
| Specification | Dimension |
|---|---|
| Bolt Rod Diameter | 7 mm (plated steel) |
| Standard Rod Length | 300 mm (150 mm threaded section) |
| Optional Rod Length | 600 mm |
| Included Accessory | Internal frame‑mount rod guide |
| Application | Aluminium doors, aluminium windows |
Application Scenarios
Aluminium Window Hardware
Reliable flush bolting hardware for residential and commercial aluminium window assemblies, factory‑trimmable threaded rod for different frame sizes.
Aluminium Door Systems
High‑security plated steel bolt rod, ergonomic operating lever, ideal for locking inactive leaf of aluminium door sets.
Contract & Refurbishment Projects
Complete with frame‑mount rod guide, choice of 300 mm or 600 mm rod length, configurable for project‑specific requirements.
Interlock flush bolt purpose‑built for safe bolting of aluminium doors and windows
7 mm diameter plated steel rod delivers high‑security performance
Robust die‑cast zinc body and operating lever with comfortable finger grip
Standard 300 mm rod with 150 mm threaded section, factory‑trimmable to suit varying door / window sizes
Rod guide supplied as standard for fitting inside door or window frame
600 mm long rod available as optional specification
Available finishes: CP, SN
Standard quality warranty against manufacturing defects
Rod can be factory‑trimmed for custom project‑specific frame dimensions
Technical drawing and specification sheet available for tender documentation
